Allen-Bradley - Residual Current Device 63 A - 1492-RCDA4C63S
€ 460,83
door St.
€ 460,83
1
Bezorging
Aantal beschikbare items voor levering:0
Belangrijke informatie
Aantal polen - 4
Nom. (meet)stroom - 63 A
Nom. foutstroom - 0.3 A
Nom. (meet)spanning - 110 V
Nom. stoothoudspanning (Uimp) - 4 kV
Verpakking
1 St.
EAN
00885630618005
Ref Routeco
1492-RCDA4C63S
Ref leverancier
1492-RCDA4C63S
Ref commercieel
1492-RCDA4C63S
Aantal polen:
4
Nom. (meet)stroom:
63 A
Nom. foutstroom:
0.3 A
Nom. (meet)spanning:
110 V
Nom. stoothoudspanning (Uimp):
4 kV
Montagewijze:
DIN-rail
Kortsluitvastheid (Icw):
10 kA
Frequentie:
50/60 Hz
Beschermingsgraad (IP):
IP2X
Inbouwdiepte:
67 mm
Omgevingstemperatuur tijdens bedrijf:
-25...55 °C
Residual Circuit Device. Standard Configuration, 4-pole, 300mA Sensitivity, 63 A, With Delay Option
- Provides protection against current leakage to ground (earth) caused by an insulation
- loss between a live conductor and an exposed conductive part (such as an abraded wire, or a grounded person touching the live conductor)
- Suitable for protection against AC and pulsating DC (rectified AC) earth leakage current
- 30 mA sensitivity devices for personnel protection (consult local requirements)
- 100, 300 and 500 mA sensitivity devices for equipment protection
- Dual terminals allow a more secure connection of two wires, or both a wire and bus bar
- Reversible line and load connections
